散熱器
散熱器外形尺寸及主要參數
|
型號
|
迎風面積m2
|
散熱面積m2
|
凈通風截面積m2
|
表面管數
|
排數
|
連接管DN(in)
|
尺寸(mm)
|
||||||||||
|
A
|
B
|
A1
|
A2
|
B1
|
B2
|
D
|
n
|
N
|
m
|
M
|
|||||||
|
SZGL-5×5
|
0.257
|
10.854
|
0.123
|
9
|
2
|
1[1/2]
|
500
|
513
|
560
|
600
|
553
|
593
|
75
|
4
|
400
|
4
|
400
|
|
8×5
|
0.410
|
17.366
|
0.196
|
800
|
860
|
900
|
7
|
700
|
|||||||||
|
10×5
|
0.513
|
21.708
|
0.245
|
1000
|
1060
|
1100
|
9
|
900
|
|||||||||
|
6×6
|
0.405
|
17.366
|
0.191
|
12
|
2
|
1[1/2]
|
600
|
675
|
660
|
700
|
715
|
755
|
75
|
5
|
500
|
5
|
500
|
|
8×6
|
0.54
|
23.155
|
0.255
|
800
|
860
|
900
|
7
|
700
|
|||||||||
|
10×6
|
0.675
|
28.944
|
0.317
|
1000
|
1060
|
1100
|
9
|
900
|
|||||||||
|
12×6
|
0.81
|
34.733
|
0.381
|
1200
|
1260
|
1300
|
11
|
1100
|
|||||||||
|
8×8
|
0.67
|
28.944
|
0.313
|
15
|
2
|
2
|
800
|
837
|
860
|
900
|
877
|
918
|
75
|
7
|
700
|
7
|
700
|
|
10×8
|
0.837
|
36.18
|
0.391
|
1000
|
1060
|
1100
|
9
|
900
|
|||||||||
|
12×8
|
1.004
|
43.416
|
0.469
|
1200
|
1260
|
1300
|
11
|
1100
|
|||||||||
|
14×8
|
1.172
|
50.652
|
0.547s
|
1400
|
1460
|
1500
|
13
|
1300
|
|||||||||
|
14×10
|
1.474
|
64.159
|
0.683
|
19
|
2
|
2[1/2]
|
1400
|
1053
|
1460
|
1500
|
1093
|
1133
|
75
|
9
|
900
|
13
|
1300
|
|
16×10
|
1.685
|
73.325
|
0.78
|
1600
|
1660
|
1700
|
15
|
1500
|
|||||||||
|
18×10
|
1.895
|
82.490
|
0.878
|
1800
|
1860
|
1900
|
17
|
1700
|
|||||||||
|
18×12
|
2.284
|
99.857
|
1.052
|
23
|
2
|
3
|
1800
|
1269
|
1860
|
1800
|
1309
|
1349
|
75
|
11
|
1100
|
17
|
1700
|
|
20×12
|
2.538
|
110.952
|
1.169
|
2000
|
2060
|
2100
|
19
|
1900
|
|||||||||
|
22×12
|
2.792
|
122.047
|
1.286
|
2200
|
2260
|
2300
|
21
|
2100
|
|||||||||
|
25×12
|
3.173
|
138.69
|
1.461
|
2500
|
2560
|
2600
|
24
|
2400
|
|||||||||
